Hughes & Kettner TriAmp Mark III

Description

The Hughes & Kettner Triamp Mark 3

No limits. No compromises. This is what you get when 30 years of tube amp expertise combine with an absolute freedom of engineering. The result is an amp boasting a range of professional sounds not offered by any other amp anywhere on the planet. And best of all, TriAmp Mark 3?s breathtaking versatility and inspirational tonality is matched only by its ease and joy of use.

Each of TriAmp Mark 3?s six independent, action-packed channels represents a whole era of tone, and each of these six eras can be routed to three independent tube power amps.

But there?s more. You can also combine two or even all three of the power amps, merge different power amp characters, and play TriAmp Mark 3 with up to 150 watts of sheer tube power. This effectively lets you custom tailor your amp in the amp, recalling up to 128 sound constellations with the touch of a button via MIDI.

And if that?s not enough, TriAmp Mark 3 leaves our factory in St. Wendel, Germany equipped with two pairs of 6L6 power tubes and one pair of EL34s ? but it works equally well with other tube types too. The revised TSC System ? Tube Safety Control, which automatically and constantly biases tubes and keeps your amp in good health ? allows you to combine KT66s, KT77s, KT88s, 6550s, 5881s, 7581s and/or 6CA7s. Imagine what this could do for your trademark sounds. TriAmp Mark 3 genuinely lets you usher in a new era of tone!

-Includes footswitch & amplifier cover

Full specs:
FX LOOP   Serial/parallel, switchable
SPEAKER OUTPUT   1 x 4 Ω, 1x 8 / 2 x 16 Ω, 1 x 16 Ω
DIMENSIONS   740 x 393 x 254 mm
WEIGHT   22 kg/48.5 lbs.
CHANNELS
1A:   50s Californian Clean
1B:   60s British Clean
2A:   70s British Lead
2B:   80s Brown Sound
3A:   90s Californian High Gain
3B:   Modern-Day High Gain and beyond
POWER
POWER AMP TUBES (AS SHIPPED)
POWER OUTPUT 8 OHMS   THD=10% / THD=5%
2X EL34   84 watts / 34 watts
2X 6L6   72 watts / 30 watts
4X 6L6   126 watts / 93 watts
2X 6L6 + 2X EL34   132 watts / 95 watts
4X 6L6 + 2X EL34   145 watts / 116 watts
FOOTSWITCH
MIDI BOARD TSM 432 (INCLUDED)
SWITCHING FUNCTIONS   Preset Mode ? 32 banks, 4 presets, FX / Stomp Box Mode ? Channels, Boost
MIDI
MIDI IN   7-pin (5-pin compatible), 20 V DC phantom power (150 mA)
MIDI OUT/THRU   5-pin
RED BOX AE (Ambience Emulation)
RED BOX DI OUT XLR, BALANCED
IMPEDANCE   2 kOhms
OUTPUT LEVEL   0 dBV (balanced)
MAX. OUTPUT LEVEL   +12 dBV
